FPC Laser PCB Depaneling Machine CO2 With Precise Cutting System

  • 1
  • 2

Brand Name : Winsmart

Model Number : SMTL600

Certification : CE

Place of Origin : China

MOQ : 1 set

Price : USD1-150K/set

Payment Terms : L/C, T/T, Western Union

Supply Ability : 100 sets per month

Delivery Time : 5-30 days

Packaging Details : Plywood case

Working Area : 600x600mm

Exhaust System : Yes

Way : Non-contact Cutting

Water Cooler : Yes

Condition : New

Name : Laser PCB Depaneling

Contact Now

FPC Laser PCB Depaneling Machine Clean and Precise Cutting System

Suitable Processing Materials:

1. Flexible circuit boards, rigid circuit boards, rigid-flex circuit board sub-board processing.

2. Rigid, flexible circuit board sub-board processing component is installed.

3. Thin copper foil, a pressure-sensitive adhesive sheet (PSA), an acrylic film, a polyimide coating film.

4. Thickness of 0.6mm or less precision ceramic cutting, dicing; variety of cutting the base material (silicon, ceramics, glass, etc.)

5. Etching precision molding various functional films, an organic film and other precision cutting.

6. Polymer: polyimide, polycarbonate, polymethyl methacrylate, FR-4, PP, etc.

7. Functional film: gold, silver, copper, titanium, aluminum, chromium, ITO, silicon, poly-crystalline silicon, amorphous silicon and a metal oxide.

8. Brittle material: monocrystalline silicon, polycrystalline silicon, ceramic and sapphire.

Specification:

Laser Q-Switched diode-pumped all solid-state UV laser
Laser Wavelength 355nm
Laser Source Optowave UV 15W@30KHz
Positioning Precision of Worktable of Linear Motor ±2μm
Repetition Precision of Worktable of Linear Motor ±1μm
Effective Working Field 600mmx600mm(Customizable)
Scanning Speed 2500mm/s (max)
Working field 40mmх40mm

Features:

No mechanical stress

Lower tooling costs

Higher quality of cuts

No consumables

Simple software changes enable application changes

Display:

FPC Laser PCB Depaneling Machine CO2 With Precise Cutting SystemFPC Laser PCB Depaneling Machine CO2 With Precise Cutting SystemFPC Laser PCB Depaneling Machine CO2 With Precise Cutting System

Laser PCB Depaneling Machine FAQ:

Q: What kind of PCBs are workable to use this machine?

A: FPC and FR4 panels, covering v score and tab boards.

Q: What is laser head of the machine?

A: We use USA Optowave laser.

Q: What kind of laser source you provide?

A: Green, CO2, UV and picosecond.

Q: What is cutting speed?

A: It depends on PCB material, thickness and cutting effect requirements.

Q: Does it cause dust during cutting?

A: No dust, but smoke, machine comes with exhaust system and water cooler
